THÔNG SỐ KỸ THUẬT:

Tech Specs

• SoC

  Snapdragon® 8cx Gen 3 Compute Platform

• CPU

  8-core CPU

  – 4x Kryo Prime @3.0GHz

  – 4x Kryo Gold @2.4GHz

  – 64-bit CPU Architecture

  – 5nm process technology

• GPU

  Qualcomm® Adreno™ 690 GPU

  – Support DirectX 12

  – Support DirectML

  – Support OpenGL ES 3.2

  – Support Vulkan 1.3

  – Support OpenCL 2.0

• AI

  Qualcomm® AI Engine

  – Up to 29+ TOPS

• RAM

  LPDDR4X

  – Capacity: Up to 32GB

  – Memory bus width: 128-bit (8 channel, 16-bit per channel)

• Codec

  Qualcomm® Adreno™ VPU (5th-generation UHD video processing unit)

  – Video decoder: up to 4K@120

  – Video encoder: up to 4K@60

  – Native decode support: H.265 Main 10 / H.265 Main / H.264 High / VP9 Profile 2

  – Native encode support: H.265 Main 10 / H.265 Main / H.264 High

• Storage

  1x microSD Card Slot

  1x UFS Module Connector (UFS 3.1 gear 4 x2)

  1x M.2 M Key 2280 Slot (PCIe 3.0 x4)

  1x M.2 M Key 2280 Slot (PCIe 3.0 x2)

• Display

  1x 1x HDMI 2.1 FRL (Standard Type-A), up to 4K@120

  2x USB Type-C (USB 3.1, DisplayPort 1.4 Alt Mode), up to 4K@120

• Wireless

  1x M.2 E Key 2230 Slot for WiFi / Bluetooth

  – Supports The Latest Wi-Fi 7 Wireless Module (Only V1.3 and later versions support Wi-Fi 7)

• Ethernet

  2x 2.5GbE RJ45 Port

• USB

  2x USB 3.2 Gen 2 Type-C Port (DisplayPort 1.4b Alt Mode)

  2x USB 3.2 Gen 2 Type-A Port

  2x USB 2.0 Type-A Port

  1x USB Type-C Port for Power

• Audio

  1x 3.5mm Headphone Jack

  1x Mic Input Connector

• Power

  1x USB Type-C Port for Power

  1x Power Input Header

  – 12-20V power input

  – Support external power button

• Other

  1x Power Button

  1x EDL Button

  1x RTC Connector

  1x FAN Connector

  1x FPC Connector (PCIe 3.0 x1)

  1x 40-Pin GPIO Header

  – Support UART / I2C / SPI / GPIO

• Software

  Radxa OS

  Windows

  Ubuntu

  Armbian

  Arch Linux

  Nix OS

• Dimensions

  100 mm x 75 mm

  https://radxa.com/products/dragon/q8b#downloads
